Di-Log 1000V Non Contact Voltage Detector DL107

The DL10x Series includes two models, DL107 and DL108, with detection ranges from 24V to 1000V AC and a frequency range of 50Hz/60Hz.
Both models provide contact-free audible and visual indications of AC voltages, with the DL108 featuring a selectable vibration mode and an IP67 rating for water and dust resistance.
The detectors are drop tested to 1 meter (DL107) and 2 meters (DL108), ensuring durability in various environments.
Key features include a built-in LED flashlight, auto power-off to extend battery life, and the ability to detect cable breaks and phase in sockets.
The devices operate within a temperature range of 0°C to 40°C and have a safety rating of CAT IV 1000V, making them suitable for high-risk electrical work.

Detailed description

Features:

Detects AC voltages between 24V and 1000V (low mode) and 90V to 1000V (high mode).
Provides audible and visual indication of voltage presence.
Includes a built-in LED flashlight for convenience.
Offers selectable vibration mode (DL108 only) for industrial environments.
Quick detection of cable breaks and phase detection in sockets.
Auto power-off feature to extend battery life.
Drop-tested for durability (1m for DL107, 2m for DL108)

Specifications:

DL107: Basic model with 1m drop test and no vibration mode.
DL108: Advanced model with vibration mode, IP67 rating, and 2m drop test.
Both models operate in temperatures between 0°C and 40°C and have a storage range of -20°C to 50°C.
Dimensions: DL107 (150mm x 18mm x 23mm), DL108 (160.5mm x 21.5mm x 25mm).
Weight: DL107 (50g), DL108 (72g).
Power supply: 2 x 1.5V AAA batteries (supplied).

Certifications:

Complies with EN 61010-1, EN 61010-2-030, EN 61326-1, and EN 61326-2-2 standards
