LINIAN SUPERCLIP BLACK, 15-18mm 25pk. 1LSB1518
£7.98
{£9.58} Inc VAT
6 in stock
The LINIAN SUPERCLIP has many features including:
- Colour: Black
- Size: For cables with an overall diameter between 15-18mm
- Equivalent cleat size: 7 (CC7)
- Recommended spacing: 300mm
- Hole diameter: 10mm*
- Hole depth: 40mm
- Supports a max tensile load of 44kg
- SWA cables
- PVC/metal conduit
- Bunched cables
- Anchor fixings for wire etc
- Use with steel cable ties
- Use with outdoor trunking
- 18th Edition Compliant
- Corrosion Resistant & UV Stable
- Fire-resistant >1200°C
- BSEN 50200 120 minutes fire time
- DIN 4102-12 DIN 90 minutes fire time
- CE & CA Certified
- Single-component design
- No plugs, screws or washers needed
Specification
| Cable code | Linian Super Clip | Cable diameter (mm) |
| NYY3C4 | 12-14mm | 13.7 |
| NYY3C6 | 15-18mm | 14.7 |
| NYY3C10 | 15-18mm | 17.4 |
| NYY3C16 | 18-20mm | 19.5 |
| NYY5C4 | 15-18mm | 14.9 |
| NYY5C6 | 15-18mm | 17.3 |
| NYY5C10 | 20-22mm | 20.6 |
| NYY5C16 | 20-22mm | 22.4 |
| EV-ULTRA3C4.0 | 12-14mm | 13.6 |
| EV-ULTRA3C6.0 | 12-14mm | 14.4 |
| EV-ULTRA3C4.0SWA | 15-18mm | 15.0 |
| EV-ULTRA3C6.0SWA | 15-18mm | 16.8 |
| EV-ULTRA3C4.0CAT5 | 15-18mm | 15.0 |
| EV-ULTRA3C6.0CAT5 | 15-18mm | 16.5 |
| EV-ULTRA3C710CAT5 | 15-18mm | 17.5 |
| EV-ULTRA3C716CAT5 | 20-22mm | 20.0 |
| EV-ULTRA3C4.0CAT5SWA | 15-18mm | 16.7 |
| EV-ULTRA3C6.0CAT5SWA | 18-20mm | 19.0 |
| EV-ULTRA3C710CAT5SWA | 20-22mm | 20.5 |
| EV-ULTRA3C716CAT5SWA | 20-22mm | 22.5 |
Additional Information
Instillation:Â
To install, drill a hole, slide the clip over the cable or conduit, and push it in! No plugs, screws, washers, cleats or nail-in clips are needed.
Expertly designed to save time, money and lives, this remarkable evolution of a vital building component can help you make every job faster, safer, simpler and tidier!
Additional Information:
Equip yourself with an extraordinary upgrade in cable clip design that delivers major benefits in efficiency, safety and value for money. The LINIAN SuperClip™ is a single-component, 18th Edition-compliant, fire-rated fixing. Perfected through years of development, this exceptional innovation looks simple – and it is.
*+/- 0.5mm. Varies for best fixing according to the substrate.
See data sheet for further details.
Sold in packs of 25.
