matt:e SP-IC80-SPD Single phase unit with isolator for loads up to 7.4kW with Type 2 SPD, load curtailment at 80A.
£226.38
{£271.66} Inc VAT
matt:e SP-IC80-SPD Single phase unit with isolator for loads up to 7.4kW with Type 2 SPD, load curtailment at 80A.
The matt:e SP-IC80-SPD is a single-phase connection unit, with Automatic Reset, PEN Fault Protection, built-in Type 2 SPD and 80A Load Curtailment.
The load curtailment functionality isolates the EV charge point from the supply when the household consumption load level rises above the pre-set limit. The power supply is automatically restored to the charge point once the load reduces to a satisfactory level.
The single-phase protection device unit offers a simple, cost effective, compliant, solution for PEN fault protection. It allows for the connection of EV charge points to the PME earthing facility without the use of earth electrodes.
Helping to facilitate compliance with BS:7671. 2018 Amendment 2, 2022 Regulation 722.411.4.1 (iv).
Product Features and benefits
- Built in PEN fault protection
- No Earth Electrodes required
- Facilitates compliance with regulation 722.411.4.1 (iv) and regulation 722.311.20
- Helps reduce disruptive and costly groundworks
- Removes the risk of striking buried services
- Simple wire in wire out connection
- Built-in Type 2 SPD
- Automatic Reset
- Load Curtailment
- Suitable for single phase loads up to 7.4kW
- Standard 1 Year parts warranty
- Designed and Built in the UK
- Matt:e type SP-IC80-SPD
Specifications
- Colour – White
- Dimensions (H x W x D) – 225 x 275 x 106mm
- Voltage rating – 230V, single phase
- Frequency – 50Hz
- Max. Power Rating – 7.4kW
- IP rating – IP2X (Indoor)
- Material – Mild steel
- Finish – Powder-coated
- Warranty – 1 Year
- Build Type – Pre-configured connection centre
- Load Curtailment – Yes
- SPD Included – Yes
- Main Incoming Supply – Single-phase (230V)
- Protection Included – PEN Fault, Auto-reset
Downloads
Delivery information
This product is delivered directly from the manufacturer, and will be prepared to your specific order.
Dispatch is 4-7 days from the date of order, and delivery is a 24 hour service.
Any available delivery tracking information will be added to your order, and emailed automatically, as soon as it is available.
Made to Order
This item is made to order, or shipped from overseas to order. Please expect a 3-5 working day lead time before dispatch.
Under our Returns policy, this items is not eligible for return, for either business customers or consumers.
-
