T24-100/5A

• Split Core Current Transformer, 24mm Aperture, 100A Primary input, 5A Secondary Output.

Split Core CT Series
Frequency: 50-60Hz
Accuracy: ±1% between 5% – 120%
Insulation voltage: 600V AC
Maximum primary voltage: 5000V AC
Dielectric strength: 2.5KV/1mA/1min
Operating temperature: -15°C to +60°C
Operating humidity: <85%
Case material: PC / UL94-V0
Bobbin: PBT
Core: Permalloy
Internal structure: Epoxy

SPC – ESCT Series Current Transformers Datasheet – T24 & T36
