WCED High immunity 2 pole 63A 30Ma Type A RCD. WAR2125-030

WCED High immunity 2 pole 63A 30Ma Type A RCD. WAR2125-030

2 pole 63A 30Ma Type A
Dimensions (W x H x D mm) – 36 x 82 x 70

The WCED brand Type A RCDs detect and respond to sinusoidal
residual AC currents and residual pulsating currents up to 6mA
Mode: electro-magnetic
Residual current characteristics: A
Rated operational voltage: 230/400V
sensitivity: 100 mA Rated conditional short-circuit current: 6kA
Mechanical durability: 4000 cycles
Electrical durability: 2000 cycles
IP degree of protection:
IP20 conforming to BS EN 60529 Ambient temperature: -25 ° C —
+40 ° C
Complies with BS EN 61008-1
