matt:e EVU-3-32-TP-R Connection centre with O-PEN® and manual reset 5 pole isolator with 3 x 32A TPN Type A RCBOs.
£995.00
{£1,194.00} Inc VAT
matt:e EVU-3-32-TP-R Connection centre with O-PEN® and manual reset 5 pole isolator with 3 x 32A TPN Type A RCBOs.
The EVU-3-32-TP-R from matt:e is simple single dedicated connection unit with built in O-PEN technology, which allows for the connection of 3x 32A TPN EV charge points to the existing PME earthing facility.
The unit incorporates a 5 pole isolator with built-in shunt trip which disconnects all poles including CPC in the event of a fault, manually resettable in line with BS: 7671, 2018 Amendment 1 2020 Regulation 722.411.4.1 (iii)
The O-PEN technology does not require earth rods or measuring electrodes to function correctly.
Product Features and benefits
- Built-in matt:e O-PEN technology, which allows for the connection of 3 x 32A three phase loads to the existing PME earthing facility
- Standard mild steel IP4X enclosure
- No earth electrodes required
- Phase loss protection
- 5 pole mains isolator with manually resettable shunt trip
- Standard 1 year parts warranty
- Simple wire in, wire out connection
- With 3 x 32A 4 pole Type A RCBOs
- Designed and built in the UK
Specifications
- Colour- Black
- Current Rating- 32A
- Depth- 140mm
- Dimensions- (H)550 mm x (W)360 mm x (D)140 mm
- Finish- Powder Coated
- Frequency- 50 Hz
- Guarantee- 1 Year
- Height- 550mm
- IP Rating- IP4X
- Material- Mild Steel
- Mounting- Wall
- Number of Chargepoints- 3
- Number of Ways- 3
- Ocpp Compliant- No
- Ozev Approval- No
- Packaging Types- Each
- Pen Fault Protection- Yes
- Unspsc V18- 39121110
- Unspsc V24- 39121110
- Voltage Rating- 415V
- Weight- 7kg
- Width- 360mm
