matt:e MTE/A 27-100 3P 40A Single-phase Automatic Reset PEN Fault Protection with MCB.
£120.00
{£144.00} Inc VAT
matt:e MTE/A 27-100 3P 40A Single-phase Automatic Reset PEN Fault Protection with MCB.
The matt:e MTE/A 27-100, 3P 40A is a 40A MCB with built in single-phase PEN fault protection.
The MCB is designed to facilitate compliance with BS:7671 2018, Amendment 1 2020 Regulation 722.411.4.1 (iv).
It features built in manually resettable over current protection and automatic reset for PEN faults. The unit offers simple, single connection, for PEN fault protection without the use of an additional contactor.
Ideally suited for single-phase feeder pillars, bespoke panels, EV charge points, etc.
Product Features and benefits
- Built in matt:e PEN Fault Protection
- No Earth Electrodes required
- Helps reduce disruptive and costly groundworks
- Removes the risk of striking buried services
- Simple wire-in wire-out connection
- Over current protection
- 40A MCB
- UKCA Marked
- Standard 1 Year parts warranty
Specifications
-
- Colour – Light Grey
- Dimensions (H x W x D) – 89.7 x 71 x 76.1mm
- Voltage rating – 230V, single-phase
- Frequency – 50Hz
- Load Current – 40A
- Warranty – 1 year
- IP rating – IP20 – Circuit Breaker body
- Build Type – Individual component
- Main Incoming Supply – Single-phase (230V)
- Number of Poles – 3 (1P+N+PE)
- Short Circuit Rating – 10kA
- Number of Modules – 4
- Protection Included – PEN Fault, Auto-reset
Downloads
Delivery information
This product is delivered directly from the manufacturer, and will be prepared to your specific order.
Dispatch is 4-7 days from the date of order, and delivery is a 24 hour service.
Any available delivery tracking information will be added to your order, and emailed automatically, as soon as it is available.
-
-
